The production of high resilient polyurethane insole can be made by two-component low-pressure foaming machine of high resilient polyurethane insole or automatic production line of high resilient polyurethane insole. The pictures of the machine are as follows:

High resilience polyurethane insole two components of low pressure foaming machine is to polyols and isocyanates two components of the liquid raw materials stored in two material storage tank respectively, with two rotary precision gear metering pump to the mixed system, the pressure under the action of mixing head open, two components were injected into the small in the mixing chamber, a mixing blade high speed stirring and mixing effect, make the material liquid evenly, to form the required product.

Application: this model is suitable for the production of polyurethane high resilience insoles and other products.

Equipment technical parameters:

Polyester sole automatic production line equipment features:

1) high degree of intelligence. Controlled by PLC microcomputer, can set a variety of production plans and save, switch at any time, can set up to 999 stations.

2) labor saving.

3) high yield.

4) automatic mold opening and closing. Set up computer program to control cylinder opening and closing.

5) polyurethane foaming machine can work for a long time. One key can automatically clean the machine head to prevent it from blocking.

6) the mixing head mixing system rotates at high speed to fully mix and stir the raw materials and improve the foaming quality.

7) low power consumption. The hot water circulation system is used to heat the aluminum plate at the bottom of the mold rack, thus heating the mold and maintaining the required foaming temperature.

Equipment technical parameters:

??
